PIC12F509-I/SN

PIC12F509-I/SN, Flash Microcontroller, SOP, 25mA, 75mA, Microchip Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.41~0.41 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
100 ~ 1000 :	0.41 / Piece

PartNumber:: PIC12F509-I/SN

Brand:: Microchip Technology - Microchip | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 50000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Sophia's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-27

From Other Seller

Part Number:PIC12F509-I/SN
US $0.41 - 0.41
Quantity:

piece

Product Summary

The PIC12F509-I/SN is a Flash Microcontroller.

Parametrics

PIC12F509-I/SN absolute maximum ratings: (1)Ambient temperature under bias: -40℃ to +125℃; (2)Storage temperature: -65℃ to +150℃; (3)Voltage on VDD with respect to VSS: 0 to +6.5V; (4)Voltage on MCLR with respect to VSS: 0 to +13.5V; (5)Voltage on all other pins with respect to VSS: -0.3V to (VDD + 0.3V); (6)Total power dissipation(1): 800 mW; (7)Max. current out of VSS pin: 200 mA; (8)Max. current into VDD pin: 150 mA; (9)Input clamp current, IIK (VI < 0 or VI > VDD): ±20 mA; (10)Output clamp current, IOK (VO < 0 or VO > VDD): ±20 mA; (11)Max. output current sunk by any I/O pin: 25 mA; (12)Max. output current sourced by any I/O pin: 25 mA; (13)Max. output current sourced by I/O port: 75 mA; (14)Max. output current sunk by I/O port: 75 mA.

Features

PIC12F509-I/SN features: (1)In-Circuit Serial Programming(ICSP); (2)In-Circuit Debugging (ICD) support; (3)Power-on Reset (POR); (4)Device Reset Timer (DRT); (5)Watchdog Timer (WDT) with dedicated on-chip RC oscillator for reliable operation; (6)Programmable code protection; (7)Multiplexed MCLR input pin; (8)Internal weak pull-ups on I/O pins; (9)Power-saving Sleep mode; (10)Wake-up from Sleep on pin change.
