Product Summary
The CXA2064M is a US Audio Multiplexing Decoder. The CXA2064M is an IC designed as a decoder for the Zenith TV Multi-channel System. Functions include stereo demodulation, SAP (Separate Audio Program) demodulation, dbx noise reduction. The applications of the CXA2064M include TV, VCR and other decoding systems for US audio multiplexing TV broadcasting.
Parametrics
CXA2064M absolute maximum ratings: (1)Supply voltage : 11 V; (2)Operating temperature : -20 to +75 ℃; (3)Storage temperature : -65 to +150 ℃; (4)Allowable power dissipation : 1000 mW; (5)STID, SAPID drive current : 2 (max.) mA; (6)Range of Operating Supply Voltage : 9 ±0.5 V.
Features
CXA2064M features: (1)Adjustment free of VCO and filter; (2)Audio multiplexing decoder and dbx noise reduction decoder are all included in a single chip. Almost any sort of signal processing is possible through this IC; (3)Various built-in filter circuits greatly reduce external parts; (4)This IC is near pin to pin compatible with the CXA2020M.
Diagrams
